Tractor Mounted Wood and Banana Chipping Machine
TDO-700M
It breaks down waste materials that contain high amounts of water, such as collected bananas, palm trees and various seedlings, into small pieces, turning them into wood chips. Plant waste is left to ferment for 3-4 months, after which it is ready to be spread on the soil surface.
TDO-700M
Engine Features
Min. 35 Hp Tractor Power
Capacity
Max. 9 cm / Banana, Palm etc. 26 cm
Number of Blades
3 PCS Sharpenable Blades
Feeding System
Self-Feeding with Free Fall
Bunker Entrance
(H)53 / (L)70 cm
Discharge System
Side Discharge System
Transporter System
Tractor with 3 suspension arms
Width x Length x Height
106 X 137 X 140 cm
Weight
350 Kg
Warranty
2 Years
The Aydınmaksan TDO-700M High-Capacity Wood Chipping for Tractors is designed specifically for shredding branches of plants with high water content, such as banana and palm trees.
It is a powerful and efficient machine compatible with tractors of 35 HP and above.
Thanks to its replaceable blades made from special Swedish steel, it can easily grind branches up to 9 cm in diameter and plant trunks such as banana and palm trees up to 26 cm in diameter.
It provides high efficiency with an average grinding capacity of 1-1.5 tonnes per hour.
The ground materials can be used as solid fuel, burned in fireplaces, or used in composting. This helps to utilise waste accumulated in nature and provides an environmentally friendly solution.
The side discharge system allows the ground materials to be easily discharged.
Thanks to the hydraulic drive feeding system, the speed can be adjusted according to the thickness of the materials to be shredded, and the feed process can be kept under complete control.
This increases both work safety and machine efficiency.
It can be easily attached to and transported by a tractor thanks to the T-connection. The blades have been specially heat-treated to increase their durability. The machine has been made durable through grinding and powder coating processes.
Aydınmaksan offers a 2-year warranty for the TDO-700M. Additionally, we continue to support our customers with our after-sales services.
The TDO-700M is entirely domestically produced and is delivered to you after passing quality control.
Transform garden waste into energy-efficient resources with Aydınmaksan TDO-700M.
It is the most effective solution for disposing of plant waste with high water content, such as banana and palm trees.
-
1. TRACTOR DRIVEN ENGINE
Works with Min. 35 Hp Tractor Power.
-
2. WORKING CAPACITY
9 cm Chipping Capacity (Banana, Palm, etc. 26 cm Chipping Capacity) Provides Maximum Benefit.
-
3. NUMBER OF BLADES
3 Sharpenable Blades.
-
4. FEEDING SYSTEM
Easy to use thanks to self-feeding with free fall.
