Electric Sawdust Machine
TM-510E
Depending on the humidity and tree species, it has the capacity to grind branches up to 8 cm in diameter into chips with its 4 cutting blades. At the same time, with 32 crusher blades on it, it allows you to crush the chips into powder sawdust thanks to the sieve on it. The finished chips can be used as solid fuel, pellet fuel or for manufacturing, heating and laying on the ground in poultry farming or for heating in pyrolysis boilers, fireplaces, stoves and other heating devices. In addition, the resulting materials can be used in biomass power plants.
TM-510E
Engine Power
15 KW Electric Three Phase
Capacity
8 cm (maximum)
Number of Blades
4 Cutting Blades / 32 Shredding Blades
Hammer Blades
24 Pcs
Sieve Diameter
12 mm (Optional)
Transport
Front Wheeled with Transport Handles
Tire Size
4.00-8 Lastik
Length X Width X Height
134 X 105 X 150 cm
Weight
285 Kg
Warranty
2 Years
Meet the TM-510E, a reliable partner on your path to energy independence!
Turn wood waste into a valuable resource with the TM-510E Professional Wood Chipper!
Thanks to its special Swedish steel blades and 32 Hardox steel shredder blades, it easily shreds branches up to 8 cm in diameter into powdery sawdust.
High frequency induction heat treated blades are long lasting and high performance.
Powered by a 15 kW three-phase electric motor, our machine provides effective shredding regardless of humidity and tree species.
You can utilize the sawdust you obtain in many areas such as solid fuel, pellet fuel, heating in animal husbandry.
TM-510E, which is completely produced in our own factory, has a long service life thanks to its powder coating.
We support you 24/7 with our wide service network all over Turkey.
Moreover, we offer a 24-month warranty and a gift carrying handle.
-
1. ELECTRIC MOTOR
15 kW Electric Three Phase Motor.
-
2. WORKING CAPACITY
8 cm Chipping Capacity.
-
3. NUMBER OF BLADES
3 Cutting Blades / 24 Shredding Blades.
-
4. FEEDING SYSTEM
Easy to use thanks to self-feeding with free fall.
Let us call you
Bayimizle İletişime Geçin
Bayimizle İletişime Geçin
AYDINTARIM
PRODUCT GALLERY
Make Your Work Easier
WHY SHOULD I CHOOSE TM-510E?
Practical Movement Ability
Our models provide convenience to our users throughout the harvesting process thanks to their easy mobility.
Low Fuel Consumption
With the innovative technologies we currently use and develop, we ensure that our products operate with minimum fuel. With every innovative R&D study we conduct, we aim to keep your fuel costs at a minimum level.
High Efficiency
Our products increase your efficiency by eliminating your labor costs, which are the biggest outputs of agricultural mechanization.
